FL1850.3-R11

Report Status
Approved
Code Version
2017 Florida Building Code
Application Type
Revision
Folio:
Model:

Bertha HV Accordion Shutter - Blade 1 Only (HVHZ) - Drwg# 17-122

Database:
Florida Product Approval
Source Link:
Description:

Extruded aluminum interlocking blades retained by tracks (top and bottom) for storm protection

Listing Details
Category:
Impact Protection Devices
Subcategory:
Accordion
Evaluator:
Walter A. Tillit, Jr., P.E. - PE-44167
Validator:
John Henry Kampmann Jr.
Official Site Status:
Approved
Compliance Method:
Evaluation Report from a Florida Registered Architect or a Licensed Florida Professional Engineer
Approval Method:
Method 1 Option D
Entity:

Specifications
Submission Date:
October 3, 2017
Validation Date:
October 13, 2017
Expiration Date:
12/31/2021
HVHZ Approved:
Yes
Impact Resistant:
Yes [FL]
Possible CSI Codes:
CSI Code: 08 11 69.23 - Aluminum Storm Doors and Frames
CSI Code: 05 15 13 - Aluminum Wire Rope Assemblies
CSI Code: 08 12 16 - Aluminum Frames
CSI Code: 05 14 00 - Structural Aluminum Framing
CSI Code: 10 26 16.16 - Protective Corridor Handrails
Other:
Large missile level D. Max. span is 16-0 and 14-9 for 30 psf ASD negative load depending on centermates and locking rod configuration for the HV1 blade, 8'-0 for +64, -72 psf load for HV blade for Keystone mountings 7'-0 for +75, -75 psf for metals stud mountings and 8-0 for 110 psf. for HV1 and HV1A working in unison. See sheets 7, 11, 20 and 19 respectively of installation drawings for other spans and pressures.
Notes:


Date Submitted: October 3, 2017

Date Validated: October 13, 2017

Entity:

Compliance Method: Evaluation Report from a Florida Registered Architect or a Licensed Florida Professional Engineer

Other: Large missile level D. Max. span is 16-0 and 14-9 for 30 psf ASD negative load depending on centermates and locking rod configuration for the HV1 blade, 8'-0 for +64, -72 psf load for HV blade for Keystone mountings 7'-0 for +75, -75 psf for metals stud mountings and 8-0 for 110 psf. for HV1 and HV1A working in unison. See sheets 7, 11, 20 and 19 respectively of installation drawings for other spans and pressures.

Official Site Status: Approved

Subcategory: Accordion
Manufacturer Info
The American Shutter Systems Association, Inc. (ASSA) is a non-profit trade association dedicated to promoting the interests of the shutter industry. Founded in 1980, ASSA represents shutter manufacturers, distributors, and retailers, as well as related businesses such as shutter installers and repair specialists. The association works to improve industry standards, educate consumers about the benefits of shutters, and provide networking opportunities for its members. View all listings
* This manufacturer has not claimed their profile. Any logo or description displayed above has been generated by AI.
Contact Information
Representative:
Bill Feeley
Address:
4268 Westroads Drive,
West Palm Beach, Florida 33407 USA
