FL2681.1-R5

Report Status
Approved
Code Version
2017 Florida Building Code
Application Type
Revision
Folio:
Model:

Bertha Colonial Shutter with clips or storm bars- (Non-HVHZ) Drawing#17-114

Database:
Florida Product Approval
Source Link:
Description:

Extruded aluminum blades assembled together and retained by jambs/headers to provide hurricane protection

Listing Details
Category:
Impact Protection Devices
Subcategory:
Colonial
Evaluator:
Walter A. Tillit Jr. - PE-44167
Validator:
John Henry Kampmann Jr.
Official Site Status:
Approved
Compliance Method:
Evaluation Report from a Florida Registered Architect or a Licensed Florida Professional Engineer
Approval Method:
Method 1 Option D
Entity:

Specifications
Submission Date:
September 20, 2017
Validation Date:
October 18, 2017
Expiration Date:
12/31/2021
HVHZ Approved:
No
Impact Resistant:
Yes [FL]
Possible CSI Codes:
CSI Code: 07 46 16 - Aluminum Siding
CSI Code: 08 12 16 - Aluminum Frames
CSI Code: 05 14 00 - Structural Aluminum Framing
CSI Code: 08 11 69.23 - Aluminum Storm Doors and Frames
CSI Code: 05 14 13 - Architecturally-Exposed Structural Aluminum Framing
Other:
Large missile.Max.width is 72" and max.height is 54" for double panels(square)with clips and +65,-65 psf A.S.D.design load,and max.width is 144" and max. height is 54" for quadruple panels(square)with clips.See sheets 13 and 14 for additional schedules.Max width is 36.5 with Max. height of 67 for +60,-81 psf double (square) panels with storm bars or max. width is 61 with 73 max. height for +51,-70 psf quadruple (square)panels with storm bars.
Notes:


Date Submitted: September 20, 2017

Date Validated: October 18, 2017

Entity:

Compliance Method: Evaluation Report from a Florida Registered Architect or a Licensed Florida Professional Engineer

Other: Large missile.Max.width is 72" and max.height is 54" for double panels(square)with clips and +65,-65 psf A.S.D.design load,and max.width is 144" and max. height is 54" for quadruple panels(square)with clips.See sheets 13 and 14 for additional schedules.Max width is 36.5 with Max. height of 67 for +60,-81 psf double (square) panels with storm bars or max. width is 61 with 73 max. height for +51,-70 psf quadruple (square)panels with storm bars.

Official Site Status: Approved

Subcategory: Colonial
Manufacturer Info
The American Shutter Systems Association, Inc. (ASSA) is a non-profit trade association dedicated to promoting the interests of the shutter industry. Founded in 1980, ASSA represents shutter manufacturers, distributors, and retailers, as well as related businesses such as shutter installers and repair specialists. The association works to improve industry standards, educate consumers about the benefits of shutters, and provide networking opportunities for its members. View all listings
* This manufacturer has not claimed their profile. Any logo or description displayed above has been generated by AI.
Contact Information
Representative:
Bill Feeley
Address:
4268 Westroads Drive,
West Palm Beach, Florida 33407 USA
