FL42363

Save to Favorites
Most Recent Revision

FL42363-R2

Revision Folder

Manufacturer
BAKER METAL WORKS & SUPPLY, INC.
Report Status
Approved
Code
2023 Florida Building Code
Validator
Lucas A. Turner, P.E., MBA
Approvals in this folder:
PR Instl Docs FL42363 R2 II B14Cor Dwg2
FL42363.1-R2
26 Ga. 1 1/4" Steel Corrugated Roof Panel, 23 3/4" Wide x 1/4", over 1/2" Plywood (or) 5/8" Plywood (or) 7/16" OSB with 1x4 Wood Battens.
1 1/4" Corrugated 26 Ga. Steel Roof Panel
PR Instl Docs FL42363 R2 II BCorWB Dwg
FL42363.2-R2
26 Ga. Steel 2 1/2" Corrugated Roof Panel, 21 1/2" Wide x 1/2", over 1/2" Plywood with 1x4 Wood Battens (or) 7/16" OSB with 1x4 Wood Battens.
2 1/2" Corrugated 26 Ga.Steel Roof Panel
PR Instl Docs FL42363 R2 II BCor Dwg3
FL42363.3-R2
26 Ga. Steel 2 1/2" Corrugated Roof Panel, 21 1/2" Wide x 1/2", over 1/2" Plywood (or) 5/8" Plywood.
2 1/2" Corrugated 26 Ga.Steel Roof Panel
PR Instl Docs FL42363 R2 II B5V Dwg2
FL42363.4-R2
26 Ga. Steel 5V Roof Panel, 24" Wide x 3/8" Rib Height, over 1/2" Plywood (or) 5/8" Plywood (or) 7/16" OSB with 1x4 Wood Battens.
26 Ga. Steel 5V Roof Panel
PR Instl Docs FL42363 R2 II BPBR Dwg2
FL42363.5-R2
26 Ga. Steel PBR Roof Panel, 36" Wide x 1 1/4" Rib Height, over 1/2" Plywood (or) 5/8" Plywood (or) 7/16" OSB with 1x4 Wood Battens.
26 Ga. Steel PBR Roof Panel
PR Instl Docs FL42363 R2 II BTR Dwg
FL42363.6-R2
26 Ga. Steel Tuff Rib Roof Panel, 36" Wide x 3/4" Rib Height, over 1/2" Plywood (or) 5/8" Plywood (or) 7/16" OSB with 1x4 Wood Battens.
26 Ga. Steel Tuff Rib Roof Panel
PR Instl Docs FL42363 R2 II B29TR Dwg
FL42363.7-R2
29 Ga, Steel Tuff Rib Roof Panel, 36" Wide x 3/4" Rib Height, over 1/2" Plywood (or) 5/8" Plywood (or) 7/16" OSB with 1x4 Wood Battens.
29 Ga. Steel Tuff Rib Roof Panel
PR Instl Docs FL42363 R2 II BStM Dwg3
FL42363.8-R2
26 Ga. Steel Strongman Roof Panel, 36" Wide x 9/16" Rib Height, over 1/2" Plywood (or) 5/8" Plywood (or) 7/16" OSB with 1x4 Wood Battens.
Strongman 26 Ga. Steel Roof Panel
Revision History

FL42363-R1

Revision Folder

Manufacturer
BAKER METAL WORKS & SUPPLY, INC.
Report Status
Approved
Code
2023 Florida Building Code
Validator
Lucas A. Turner, P.E., MBA
Approvals in this folder:
PR Instl Docs FL42363 R1 II B125Cor Dwg
FL42363.1-R1
23 3/4" Wide x 1/4" High, 26 Ga. Steel Corrugated Roof Panel, Over 1/2" Plywood or 5/8" Plywood.
1 1/4" Corrugated 26 Ga. Steel Roof Panel
PR Instl Docs FL42363 R1 II B5V Dwg
FL42363.2-R1
24" Wide x 3/8" Rib Height, 26 Ga. Steel 5V Roof Panel, Over 1/2" Plywood or 5/8" Plywood.
26 Ga. Steel 5V Roof Panel
PR Instl Docs FL42363 R1 II BPBR Dwg
FL42363.3-R1
36" Wide x 1 1/4" Rib Height, 26 Ga. Steel PBR Roof Panel, Over 1/2" Plywood or 5/8" Plywood.
26 Ga. Steel PBR Roof Panel
PR Instl Docs FL42363 R1 II BRib Dwg
FL42363.4-R1
36" Wide x 3/4" Rib Height, 26 Ga. Steel Rib Roof Panel, Over 1/2" Plywood or 5/8" Plywood.
26 Ga. Steel Rib Roof Panel
PR Instl Docs FL42363 R1 II BCor Dwg2
FL42363.5-R1
21 1/2" Wide x 1/2" High, 26 Ga. Steel Corrugated Roof Panel, Over 1/2" Plywood, 5/8" Plywood, or 1x4 Wood Purlins.
Corrugated 26 Ga.Steel Roof Panel
PR Instl Docs FL42363 R1 II BStm Dwg2
FL42363.6-R1
36" Wide x 9/16" Rib Height, 26 Ga. Steel Roof Panel, Over 1/2" Plywood or 5/8" Plywood.
Strongman 26 Ga. Steel Roof Panel

FL42363-R0

Revision Folder

Manufacturer
BAKER METAL WORKS & SUPPLY, INC.
Report Status
Approved
Code
2023 Florida Building Code
Validator
Lucas A. Turner, P.E., MBA
Approvals in this folder:
PR Instl Docs FL42363 R0 II BCor Dwg
FL42363.1-R0
1/2" x 21 1/2" wide 26 Ga. Corrugated Steel Roof Panel over 1/2" Plywood or 1x4 Wood Purlins.
26 Ga. Corrugated Steel Roof Panel
PR Instl Docs FL42363 R0 II BStm Dwg
FL42363.2-R0
36" Wide x 9/16" Rib Height, 26 Ga. Steel Roof Panel, Over 1/2" Plywood or 5/8" Plywood.
Strongman 26 Ga. Steel Roof Panel
