FL3557

Save to Favorites
Most Recent Revision

FL3557-R31

Revision Folder

Manufacturer
Quick Tie Products, Inc.
Report Status
Approved
Code
2023 Florida Building Code
Validator
Justin M Lanier, P.E.
Approvals in this folder:
PR Instl Docs FL3557 R31 II FL 3557.01 CMST16-54 Install 201102
FL3557.1-R31
Coiled Straps (CMST) are either 16 gauge, 14 gauge, or 12 gauge. Each strap is 3" wide with 0.177 diameter nail holes punched at 1-½ intervals along its length.
CMST16-54, CMST14-52.5, and CMST12-40 Coiled Straps
PR Instl Docs FL3557 R31 II FL 3557.10 HGA HGAM Install 201102
FL3557.10-R31
The HGA and HGAM are a 90° framing angle used to connect truss/rafter joists to wall top plates and masonry.
HGA and HGAM Gusset Angles
PR Instl Docs FL3557 R31 II FL 3557.11 LS MS Install 201102
FL3557.11-R31
Galvanized steel straps, 1-1/4 inches wide and in varying length from 9-5/8 inches to 48-5/8 inches in length with minimum thicknesses of 0.0356 inches (LS) and 0.0575 inch (MS).
LS and MS series straps
PR Instl Docs FL3557 R31 II FL 3557.12a LTS Install 251120
FL3557.12-R31
Light Twist Straps (LTS), Medium Twist Straps (MTS), and Heavy Twist Straps (HTS) come in different lengths. Straps have an offset shape to allow twisting and bending.
LTS, MTS, and HTS Twist Straps
PR Instl Docs FL3557 R31 II FL 3557.13a HA10 QGC Install 201102
FL3557.13-R31
LTT ties connect wall bottom plates/studs or joist/purlin-to-wall attachment apps. QGC connect truss & rafter to top plate where uplift load design requirements are high. HA10 are 18 gauge steel clips that fasten rafters and trusses to wall top plates.
LTT20 Light Tension Tie, QGC QuickTie Girder Connector, HA10 Hurricane Seismic Anchors
PR Instl Docs FL3557 R31 II FL 3557.14a METAS-HETAS Install 230130
FL3557.14-R31
METAS-HETAS are embedded anchors designed to connect truss/rafter joists to the top of concrete masonry unit and concrete walls. PCS are used to join center posts to beams. PCES are used to join end posts to beams
METAS/HETAS and PCS/PCES
PR Instl Docs FL3557 R31 II FL 3557.15 PAS Connector Install
FL3557.15-R31
Embedded anchors designed to connect roof purlins to a concrete or CMU wall as a purlin anchor or to connect studs to the foundation as a strap-tie hold down.
PAS18-3Z, PAS23-3Z, PAS28-3Z, PAS35-3Z and PAS51-3Z Purlin Anchor Straps
PR Instl Docs FL3557 R31 II FL 3557.16 PBA Install 241220
FL3557.16-R31
Post Base Anchors (PBAs) are used to attach the base of a wood post to a concrete foundation. The PBAs are comprised of a Post Base Strap and Stand-Off (SO) plate.
PBA Post Base Anchors: PBA44, PBA46, PBA66, PBA77, PBA88, PBA44-4P/6P and PBA66-4P/6P
PR Instl Docs FL3557 R31 II FL 3557.17 PCM EPCM Install 201102
FL3557.17-R31
PCM & EPCM Post Caps are used for post-to-beam connection applications. PCM and EPCMs are designed to resist uplift and shear loads due to wind and seismic forces.
PCM & EPCM Post Caps
PR Instl Docs FL3557 R31 II FL 3557.18 PHGT Install 240415
FL3557.18-R31
PHGT2, PHHGT3 and PHHGT4 connectors are tie downs used to join 2-ply, 3-ply or 4-ply girder trusses to wall frames or posts.
PHGT2, PHHGT3 and PHHGT4 Connectors
PR Instl Docs FL3557 R31 II FL 3557.19 QGC andQGCW Install
FL3557.19-R31
QuickTie Girder Connectors are used for truss and rafter to top plate connections where uplift load design requirements are high, and for stud hold down connections.
QGC and QGCW QuickTie Girder Connector
PR Instl Docs FL3557 R31 II FL 3557.02 CS20-250 Install 201102
FL3557.2-R31
- Coiled Straps are 20 gauge steel (CS20-250), 18 gauge steel (CS18-200), 16 gauge steel (CS16-150), or 14 gauge steel (CS14-100).
CS20-250, CS18-200, CS16-150 & CS14-100 Coiled Straps
PR Instl Docs FL3557 R31 II FL 3557.20 QT Adhesives Install
FL3557.20-R31
QE-1 Epoxy Adhesive and QE-2 Epoxy Adhesive
QuickTie Adhesives
PR Instl Docs FL3557 R31 II FL 3557.21 QuickTie Screws Install
FL3557.21-R31
QuickTie Screws are manufactured from carbon steel wire using a standard cold-formed process followed by a heat-treating process.
QuickTie Screws: SWH, SWF, SWT, SWL
PR Instl Docs FL3557 R31 II FL 3557.22 QTS Install
FL3557.22-R31
The QTS consists of wood frame QuickTie, QTX(L), where X is the QuickTie type/cable diameter and L is the length in feet.
QuickTie System (QTS): QTB(L) Blue, QTG(L) Green, QTO(L) Orange, QTR(L) Red
PR Instl Docs FL3557 R31 II FL 3557.23 RSPT Install 251014
FL3557.23-R31
Connectors designed to connect wood studs to either top or sill plates of wood framed walls
RSPT4, RSPT6, and RSPT6-2 Stud Plate Ties
PR Instl Docs FL3557 R31 II FL 3557.24 SC34 Install 221019
FL3557.24-R31
The SC34 anchor floor and ceiling joists to headers. The SC34 uses a 90° framing angle to join posts to beams and to make other right-angle connections.
SC34 Framing Angle
PR Instl Docs FL3557 R31 II FL 3557.25 SC35 SC35F Install 201102
FL3557.25-R31
The SC35 anchors floor and ceiling joists to headers. The SC35F provides solid blocking to top plates. The SC35 uses a 90° framing angle to join posts to beams and to make other right-angle connections.
SC35 Framing Angle and SC35F Framing Plate
PR Instl Docs FL3557 R31 II FL 3557.26 SPArtanSill Install 201102
FL3557.26-R31
SPArtan Sill Plate Anchors are post-installed anchors used to attach the sill plate of a wood framed wall to a concrete foundation.
SPArtan Sill Plate Anchor
PR Instl Docs FL3557 R31 II FL 3557.27 TCC Install 240415
FL3557.27-R31
TCC16L, TCC16R, TCC21L and TCC21R connectors are Tension-Compression drag strut connectors used to transfer lateral forces from a truss to shear walls.
TCC16L, TCC16R, TCC21L and TCC21R Drag Strut Connectors
PR Instl Docs FL3557 R31 II FL 3557.28 TCS18-3Z TCS20-3Z Install.pdf
FL3557.28-R31
Connectors designed to bridge/repair discontinuous wood members by transferring axial loads from one member to the other connected member
TCS 18-3Z and TCS20-3Z Tension-Compression Straps
PR Instl Docs FL3557 R31 II FL 3557.29 TR1 TR2 Install
FL3557.29-R31
TR1 and TR2 Roof Truss Clips are connectors designed for alignment control between a roof truss and non-loadbearing walls.
TR1 and TR2 Roof Truss Clips
PR Instl Docs FL3557 R31 II FL 3557.03 FASA4 Install
FL3557.3-R31
FASA4 Foundation Anchor Strap is a cast-in-place connector designed for use as an alternative to anchor bolts.
FASA4 Foundation Anchor Strap
PR Instl Docs FL3557 R31 II FL 3557.30a U-Hangers Install 221019
FL3557.30-R31
U-Hanger and Inverted Flange (IF) U-Hanger Series are face mount joist hangers used to resist gravity loads and uplift loads due to wind in one-, two- and three-ply joist assemblies in light-frame wood construction.
U-Hanger Series: UL, ULU, ULP & ULP-IF, UM, UH & UH-IF, TFLP, TFH; TSH; THJH; UMH; UHH; ULPSSH; UMSR-L; UHSR-L; UHD
PR Instl Docs FL3557 R31 II FL 3557.04 FSTHD Install
FL3557.4-R31
FSTHD8, FSTHD8J, FSTHD10, FSTHD10J, FSTHD14 and FSTHD14J are embedded strap-tie hold downs designed to secure a structure, wood-framed walls, to its foundation.
FSTHD and FSTHDJ Foundation Strap-Tie Hold Downs
PR Instl Docs FL3557 R31 II FL 3557.05 HA4 6 8 Install 201102
FL3557.5-R31
18 gauge (minimum thickness with coating 0.0466") steel clips are used to fasten rafters and trusses to wall top plates.
HA4, HA 6 and HA8 Hurricane/Seismic Clip
PR Instl Docs FL3557 R31 II FL 3557.06 HD8 Install 251015
FL3557.6-R31
Hold Down Connectors used to anchor stud walls and/or posts into concrete.
HD8
PR Instl Docs FL3557 R31 II FL 3557.07 HDTT HD Install 221014
FL3557.7-R31
HDTT, HD5, HD7, HD11, HD14, and HD15/20 Hold Downs
HDTT, HD5, HD7, HD11, HD14, and HD15/20 Hold Downs
PR Instl Docs FL3557 R31 II FL 3557.08 HDTT3 6 HD22 Install 220525
FL3557.8-R31
HDTT3 and HD22 are used to anchor stud walls and/or posts into concrete; HDTT6 Hold Down Connectors are used to anchor stud walls into concrete.
HDTT3 Hold Down, HD22 Hold Down and HDTT6 Hold Down
PR Instl Docs FL3557 R31 II FL 3557.09 HDTT45 Install 201023
FL3557.9-R31
HDTT45 Hold Down Connectors are used to anchor stud walls into concrete.
HDTT45 Hold Down
